Products » Electrical » EX Lighting Fixture

Lighting fixture for energy saving lamps (EV...)

Lighting fixture for energy saving lamps (EV...)
  • ✓ Ex protection: Ex II 2 GD Ex d IIC T.. Gb - Ex tb IIIC T..°C Db IP66
  • ✓ Certificate: CESI 12 ATEX 006
  • ✓ Installation: zone 1 - 2 - 21 - 22
  • ✓ Low copper content aluminium alloy body
  • ✓ E27 or E40 ceramic lamp holder
  • ✓ Standard power supply 230V 50/60Hz
  • ✓ Borosilicate glass globe
  • ✓ Internal/external stainless steel earth screw
  • ✓ Ral 7035 epoxy coating
  • ✓ Stainless steel guard
  • ✓ Directly connected to the lamp holder or to the terminal strip L,N, Pe section 4 mm2
  • ✓ Neoprene gaskets
  • ✓ manufacturer: cortem group-italy

Lighting fixture for discharge lamps up to 150 W (EW...)

Lighting fixture for discharge lamps up to 150 W (EW...)
  • ✓ Ex protection: Ex II 2 GD Ex d IIC T.. Gb - Ex tb IIIC T..°C Db IP66
  • ✓ Certificate: CESI 12 ATEX 006
  • ✓ Installation: zone 1 - 2 - 21 - 22
  • ✓ Low copper content aluminium alloy body
  • ✓ Borosilicate glass globe
  • ✓ Standard power supply 230V 50Hz
  • ✓ Stainless steel protective guard
  • ✓ Internal/external stainless steel earth screw
  • ✓ Ral 7035 epoxy coating
  • ✓ Neoprene gaskets
  • ✓ manufacturer: cortem group-italy

Lighting fixture for discharge lamps up to 400 W (EWA...)

Lighting fixture for discharge lamps up to 400 W (EWA...)
  • ✓ Ex protection: Ex II 2 GD Ex d IIC T.. Gb - Ex tb IIIC T..°C Db IP66
  • ✓ Certificate: CESI 12 ATEX 006
  • ✓ Installation: zone 1 - 2 - 21 - 22
  • ✓ Low copper content aluminium alloy body
  • ✓ Borosilicate glass globe
  • ✓ Standard power supply 230V 50Hz
  • ✓ Stainless steel protective guard
  • ✓ Internal/external stainless steel earth screw
  • ✓ Ral 7035 epoxy coating. Neoprene gaskets
  • ✓ manufacturer: cortem group-italy

Light Fittings for Fluorescent Lamps(Series EXLUX 6000)

Light Fittings for Fluorescent Lamps(Series EXLUX 6000)
  • ✓ As pendant light fitting or side entry lamp
  • ✓ Version with 1 or 2 lamps: 18, 36 and 58 W
  • ✓ Central locking
  • ✓ All-pole disconnection by means of an N/C switch when the lamp is opened
  • ✓ End of life switch 1 and 2
  • ✓ Ex II 2 G Ex d e IIC T4(zone 1 & 2)
  • ✓ Ex II 2 D Ex tD A21 IP 66 T80°C / T90°C(zone 21 & 22)
  • ✓ Certificate: PTB 97 ATEX 2031
  • ✓ Enclosure: glass reinforced polyester
  • ✓ manufacturer: stahl-germany

Light Fitting for Fluorescent Lamps (Series ECOLUX 6600)

Light Fitting for Fluorescent Lamps (Series ECOLUX 6600)
  • ✓ 1- or 2-lamp version: – 18 W – 36 W – 58 W
  • ✓ Enclosure in polyester resin, glass fibre reinforced and cover in polycarbonate, impact-resistant
  • ✓ Quick fasteners
  • ✓ Ex II 3 G Ex nA II T4(zone 2)
  • ✓ Ex II Ex tD A21 IP66 T* (6600/52 und 6600/54)
  • ✓ Ex II Ex tD A22 IP56 T* (6600/56)
  • ✓ Certificate:DMT 01 E 085,DMT 01 ATEX E 086X,DMT 01 ATEX E 085
  • ✓ Degree of protection:IP66 (IP64 when using breather 8162) IP56 at 58 W
  • ✓ manufacturer: stahl-germany

Lighting fixture for fluorescent tubesand LED tubes (FLFE...)

Lighting fixture for fluorescent tubesand LED tubes (FLFE...)
  • ✓ Ex protection: Ex II 2GD Ex de IIC T6 - Ex tD A21 IP 66
  • ✓ Certificate: CESI 09 ATEX 008
  • ✓ Installation: zone 1 - 2 - 21 - 22
  • ✓ Aluminium alloy heads with low copper content
  • ✓ Standard power supply 230V 50/60Hz
  • ✓ Shock-proof and temperature-resistant borosilicate glass tube
  • ✓ White aluminium internal frame that works as diffusing reflector also
  • ✓ Neoprene gaskets resistant to acids and hydrocarbons
  • ✓ Silicon resin between glass tube and aluminium heads
  • ✓ PLG2IB cap and REV2IB nickel-plated brass cable gland
  • ✓ 4 Ah or 7Ah, 6V rechargeable batteries
  • ✓ RAL 7035 epoxy coating
  • ✓ Stainless steel screws
  • ✓ manufacturer: cortem group-italy
